Smart Wearable VPU Test System
Smart Wearable VPU Test System
Vibration Excitation Simulation
High-Sensitivity Acceleration Sensing
Intelligent Signal Analysis
Overview
CRYSOUND provides a professional VPU test solution for bone-conduction voice applications in smart wearable devices, including TWS earbuds, OWS headsets, and AR glasses. This solution is designed to address the testing requirements of bone-conduction pickup under actual structural vibration conditions, providing stable, reliable, and production-ready measurement methods.
Based on advanced electroacoustic test technology, the solution integrates precision vibration excitation, high-sensitivity acceleration sensors, and intelligent signal analysis algorithms. It effectively suppresses airborne sound interference and accurately reflects the operating characteristics of the VPU under bone-conduction conditions.
Through precise measurement of key parameters such as frequency response, sensitivity, and distortion, the system helps customers maintain consistent and stable voice performance during both R&D validation and mass production testing, ensuring quality consistency for next-generation smart wearable products.
System Block Diagram
– > The host PC controls the Bluetooth dongle to connect to the device under test (DUT) and initiate production testing
– > The vibration table outputs swept-frequency signals, and the VPU records audio data, which is transmitted back via the Bluetooth dongle
– > The Bluetooth dongle controls the DUT to play swept signals, while the acceleration sensor collects vibration response data
– > The host software analyzes the data and outputs test results
Features
- High-Precision Bone-Conduction VPU Measurement
By combining vibration excitation simulation, high-sensitivity acceleration sensors, and intelligent signal analysis algorithms, the system establishes a complete bone-conduction test chain. This effectively isolates airborne sound interference and accurately reproduces the VPU’s operating state under structural vibration conditions.
The system enables stable and accurate measurement of key VPU parameters, including frequency response, sensitivity, and total harmonic distortion (THD). The high repeatability of test results provides reliable support for product development, performance comparison, and production qualification.
- Stable Acoustic Test Performance Suitable for Mass Production
When used together with shielded acoustic enclosures and standardized test fixtures, the solution effectively reduces the impact of environmental variations on test results. This ensures consistency and comparability across different test stations and production batches.
With a highly automated overall test process, the solution meets the stable testing requirements of TWS earbuds, OWS headsets, and AR glasses in large-scale mass production.
Test Items
System Devices
CRY725D Pneumatic Acoustic Test Chamber
The CRY725D is a pneumatic, drawer-style acoustic test chamber that offers superior soundproofing at low frequencies compared to the CRY725 model. This makes it particularly effective for background noise measurement. When combined with the CRY6151B and CRY algorithm, the CRY725D provides an enhanced solution for minimizing noise floor interference, making it an excellent choice for precision testing on production lines.
CRY434 Accelerometer, 1 Axis, 100mv/g, ±50g pk, 0.5Hz to 8kHz
The CRY434 is a single-axis acceleration sensor featuring a 10-32 UNF output on the side for easy mounting with a 10-32 UNF bolt. It is well-suited for detecting small movements in laboratory and scientific research, as well as for monitoring the vibration status of industrial equipment in real-time. The CRY434 can be paired with armored shielded cables to accurately measure vibration parameters such as acceleration, velocity, and displacement, even in environments with high levels of industrial or electrical interference.
